Name: F6-4GT Din-rail Industrial 4-Port 1000Base-Tx Switch
Brand: Beijing Fibridge Co., Ltd.

F6-4GT Din-rail Industrial 4-Port 1000Base-Tx Switch

Fibridge F6-4GT series network industrial switch is a high-performance ether-net access equipment developed by Beijing Fibridge. It has 4 10/100/1000 Mbps Ethernet interfaces ports. The device is built-in power module, you can choose 220V AC input or 12V DC input. The device operates at a temperature of -40ºC~+85ºC Range and a humidity of 10%~90%(No condensation).The F6 series is compact desktop design, small size, light weight, easy to place in the desktop or cabinet.

Specification of F6-4GT Din-rail Industrial 4-Port 1000Base-Tx Switch

Network Characteristics
Ethernet Protocol	Support IEEE802.3/802.3u/802.3x/802.3az, storage and forward
Flow Control	IEEE802.3x flow control, back pressure flow control
Network Interface	ETH: 10/100/1000MBase-T(X)Adaptive Ethernet RJ45 port
VLAN	No
MAC Addresses	8K
Jumbo Frame	Max size 9216
Cache	NO
Packet Buffer	8Gbps
Packet Forwarding Rate	5.952Mpps
Management	No
Optical Characteristics
Optical Interface	N/A
Fiber Core Count	N/A
Wavelength	N/A
Fiber Mode	N/A
Environmental Characteristics
Temperature & Humidity	Working temperature: -40ºC~85ºC
	Storage temperature:-40ºC~85ºC
	Working humidity:10%~90% RH No condensation
	Storage humidity:5%~90% RH No condensation
Power	AC 100-240V/50-60Hz Built-in switching power supply,
Power	DC12V 1A External power supply
MTBF	≥100000 hours
Mechanical Characteristics
Structural Dimension	163× 122× 52mm
Product Weight	0.8kg

Features of F6-4GT Din-rail Industrial 4-Port 1000Base-Tx Switch

Support IEEE802.3/802.3u/802.3x/802.3az forward mode;
Meet the requirements of reliable work in harsh electrical environment;
Support Ethernet port auto-negotiation;
Support flow control;
Industrial &Modular design make the equipment reliable and flexible;
Support overload protection;
Reverse-link protection is supported;
Support optical port hot plug;
Level of protection:IP40;
ISO9000 qualified;
Product Passes testing of the Ministry of Public Security;
Product obtains network qualification certificate.

Ordering Information of F6-4GT Din-rail Industrial 4-Port 1000Base-Tx Switch

Model	Ports	Management
F6-4GT	4 10/100/1000M RJ45 ports	No
